| Technical parameter |
| Drilling depth(M) | 50 | 150 |
| Drilling diameter(mm) | 1500 | 500 |
| Speed of turntable(r/min) | 80.3,52.1,32.18.64,10.99,10.48((reverse) |
| Torque of turntable(KN.m) | 10.9,17.4, 30.7, 52.1, 54.8 (reverse) |
| Single rope lifting capacity of windlass(KN) | 30 |
| Lifting capacity of hook(KN) | 120 |
| Bearing capacity of mast (KN) | 150 |
| The height of mast (mm) | 7240 |
| Bearing weight(t) | 15 |
| Pipe | Kelly(mm) | 182*182*5000 |
| Assistant pipe(mm) | D168*8*3000 (screwed connection) |
| Hydraulic pump | Model | CB-E532 |
| Pump delivery(ml/r) | 32 |
| Rater speed (r/min) | 2000 |
| Rated pressure (MPa) | 16 |
|
Mud pump | Flux (m³/h) | 200 |
| Suction (m) | 7.5 |
| Delivery lift (m) | 26 |
| Speed (r/min) | 1450 |
| Power (KW) | | 30 |
| Sewage pump | 6BS Sewage pump | Flux (m³/h) | 280 |
| Suction (m) | 7.5 |
| Delivery lift(m) | 18 |
| Speed (r/min) | 730 |
| Power (KW) | 30 |
| Match power | Diesel engine | Model | NC4110ZG17-20 |
| Rater power(KW) | 74 |
| Speed(r/min) | 2000 |
| Weight(t) | 15 |
| Transport size (L*W*H)(mm) | 7144*2300*8315 |
| Working size(L*W*H)(mm) | 7460*2300*3060 |
| Walking speed does not be allowed more than second gear speed. |
