LG air compressor is most economic air compressor package, but with the benefits of heavy duty working design, low maintenance cost and internal components easy exchangeable. it is flexible for air cooled and water cooled.
LG series has belt driving type (7.5 – 75kw) and direct driving model (18.5 – 355kw), working pressure from 7.5 to 13 bar(g), Free Air Delivery from 1.2 – 62 m3/min.
Frequency-controlled function can be activated according to various needs of the clients.
Variable speed drive available to dramatically reduce costs and power.
| Model | F.A.D.
m3/min | Working Pressure
Mpa | Motor
kw | Dimension (LxWxH) mm |
| LG-1.2/8 | 1.2 | 0.8 | 7.5 | 900x700x1040 |
| LG-1.0/10 | 1.0 | 1.0 | 7.5 | 900x700x1040 |
| LG-0.8/13 | 0.8 | 1.3 | 7.5 | 900x700x1040 |
| LG-1.7/8 | 1.7 | 0.8 | 11 | 1060x800x1230 |
| GL-1.5/10 | 1.5 | 1.0 | 11 | 1060x800x1230 |
| LG-1.2/13 | 1.2 | 1.3 | 11 | 1060x800x1230 |
| LG-2.4/8 | 2.4 | 0.8 | 15 | 1060x800x1230 |
| LG-2.2/10 | 2.2 | 1.0 | 15 | 1060x800x1230 |
| LG1.7/13 | 1.7 | 1.3 | 15 | 1060x800x1230 |
| LG-3/8 | 3.0 | 0.8 | 18.5 | 1080x880x1415 |
| LG-2.7/10 | 2.7 | 1.0 | 18.5 | 1080x880x1415 |
| LG-2.3/13 | 2.3 | 1.3 | 18.5 | 1080x880x1415 |
| LG-3.6/8 | 3.6 | 0.8 | 22 | 1080x880x1415 |
| LG-3.2/10 | 3.2 | 1.0 | 22 | 1080x880x1415 |
| LG-2.7/13 | 2.7 | 1.3 | 22 | 1080x880x1415 |
| LG-5/8 | 5.0 | 0.8 | 30 | 1300x1100x1650 |
| LG-4.5/10 | 4.5 | 1.0 | 30 | 1300x1100x1650 |
| LG-3.7/13 | 3.7 | 1.3 | 30 | 1300x1100x1650 |
| LG-6.2/8 | 6.2 | 0.8 | 37 | 1630x910x1220 |
| LG-5.6/10 | 5.6 | 1.0 | 37 | 1300x1100x1650 |
| LG-4.8/13 | 4.8 | 1.3 | 37 | 1300x1100x1650 |
| LG-7.1/8 | 7.1 | 0.8 | 45 | 1300x1100x1650 |
| LG-6.5/10 | 6.5 | 1.0 | 45 | 1300x1100x1650 |
| LG-5.6/13 | 5.6 | 1.3 | 45 | 1300x1100x1650 |
| LG-10/8G | 10.0 | 0.8 | 55 | 1950x1160x1550 |
| LG-8.7/10 | 8.7 | 1.0 | 55 | 1620x1230x1670 |
| LG-7.5/13 | 7.5 | 1.3 | 55 | 1620x1230x1670 |
| LG-13/8G | 13.0 | 0.8 | 75 | 2440x1160x1620 |
| LG-12/10G | 12.0 | 1.0 | 75 | 2440x1160x1620 |
| LG-10/13 | 10.0 | 1.3 | 75 | 1580x1320x1646 |
| LG-16/8G | 16.0 | 0.8 | 90 | 2560x1300x1620 |
| LG-14/10G | 14.0 | 1.0 | 90 | 2560x1300x1620 |
| LG-12/13G | 12.0 | 1.3 | 90 | 2560x1300x1620 |
| LG-20/8G | 20.0 | 0.8 | 110 | 2760x1340x1710 |
| LG-16/10G | 16.0 | 1.0 | 110 | 2760x1340x1710 |
| LG-13/13G | 13.0 | 1.3 | 110 | 2760x1340x1710 |
| LG-22/8G | 22.0 | 0.8 | 132 | 2760x1340x1710 |
| LG-20/10G | 20.0 | 1.0 | 132 | 2760x1340x1710 |
| LG-16/13G | 16.0 | 1.3 | 132 | 2760x1340x1710 |
| LG-27/8G | 27.0 | 0.8 | 160 | 2860x1510x1810 |
| LG-23/10G | 23.0 | 1.0 | 160 | 2860x1510x1810 |
| LG-20/13G | 20.0 | 1.3 | 160 | 2860x1510x1810 |
| LG-30/8G | 30.0 | 0.8 | 185 | 3400x2100x2100 |
| LG-21/13G | 21.0 | 1.3 | 185 | 2860x1510x1810 |
| LG-35/8G | 35.0 | 0.8 | 200 | 3400x2100x2100 |
| LG-30/10G | 30.0 | 1.0 | 200 | 3400x2100x2100 |
| LG-27/13G | 27.0 | 1.3 | 200 | 3400x2100x2100 |
| LG-44/8G | 44.0 | 0.8 | 250 | 3700x2200x2200 |
| LG-38/10G | 38.0 | 1.0 | 250 | 3900x2200x2200 |
| LG-33/13G | 33.0 | 1.3 | 250 | 3700x2200x2200 |
