We are one of the leading manufacturers and suppliers of portable screw air compressor. The Zuanshan mobile screw compressors, as an ideal choice for all kind of construction, mining, grounding, marine industry and many other applications. These portable screw air compressor models are equipped with an exclusive screw airend, constructed with the strongest materials and each compressor ensure exceptional performance, efficiency and long lasting maintenance life.
The specification of diesel screw portable air compressor:
Capacity: 645 cfm (18m3/min)
Working Pressure: 17 bar (1.7Mpa)
Engine Type: Cummins
Vibration isolation mount technology ensures smooth and quiet operation.
Multi-auto alarm associate with high temperature shut down protection system.
Easy to maintain with of the shelf parts.
Easy to operate with detail instruction.
Top grade diesel engines are used to ensure minimal emission to environment.
LG portable high-pressure screw air compressor is driving by Cummins diesel engine, which is apply for Mining and Construction drilling machine and power air tools, Heavy duty 24 hours and trouble free operation.
LGCY Portable Screw Compressor Specification | ||||||
Model | Capacity | Working Pressure | Diesel Engine | Weight | Dimension | |
LGCY-6/7 | 6.0 | 0.7 | YCD4B22-95, 70kw | 1400 | 3550x1800x1800 | |
LGCY-7.5/7 | 7.5 | 0.7 | YC4D80-K11, 58kw | 1850 | 3750x1920x1900 | |
LGCY-9/7 | 9.0 | 0.7 | YC4D95Z-K20, 70kw | 1850 | 3750x1920x1900 | |
LGCY-10/7 | 10.0 | 0.7 | YC4D95Z-K20, 70kw | 1900 | 3750x1920x1900 | |
LGCY-10/10 | 10.0 | 1.0 | 4BTA3.9-C125, 93kw | 1900 | 3750x1920x1900 | |
LGCY-8.5/14 | 8.5 | 1.4 | 4BTA3.9-C125, 93kw | 1900 | 3750x1920x1900 | |
LGCY-12/7 | 12.0 | 0.7 | 4BTA3.9-C125, 93kw | 2050 | 3970x1940x1900 | |
LGCY-12/7A | 12.0 | 0.7 | YC4A125Z-T10, 92kw | 2050 | 3970x1940x1900 | |
LGCY-9/14.5 | 9.0 | 1.45 | YC6B150Z-K20, 110kw | 2380 | 3970x1940x2350 | |
LGCY-12/10 | 12.0 | 1.0 | YC6B150Z-K20, 110kw | 2380 | 3970x1940x2350 | |
LGCY-12/12 | 12.0 | 1.2 | EQ6BT5.9-C160, 118kw | 2380 | 3970x1940x2350 | |
LGCY-13/13 | 13.0 | 1.3 | 6BTA5.9-C180, 132kw | 2750 | 3350x1520x2350 | |
LGCY-13/13A | 13.0 | 1.3 | YC6A190Z-T10, 140kw | 2750 | 3350x1520x2350 | |
LGCY-15/13 | 15.0 | 1.3 | WD415.23, 166kw | 3350 | 3350x1650x2500 | |
LGCY-15/13A | 15.0 | 1.3 | YC6A240-20, 177kw | 3350 | 3350x1650x2500 | |
LGCY-17/7 | 17.0 | 0.7 | 6BTA5.9-C180, 132kw | 3050 | 3350x1650x2500 | |
LGCY-13/17 | 13.0 | 1.7 | 6CTA8.3-C215, 158kw | 2380 | 3650x1800x2500 | |
LGCY-16/13 | 16.0 | 1.3 | 6CTA8.3-C215, 158kw | 3700 | 3650x1800x2500 | |
LGCY-17/14.5 | 17.0 | 1.45 | 6CTA8.3-C260, 194kw | 3700 | 3650x1800x2500 | |
LGCY-16/17 | 16.0 | 1.7 | 6CTA8.3-C260, 194kw | 3700 | 3650x1800x2500 | |
LGCY-18/17 | 18.0 | 1.7 | 6CTA8.3-C260, 194kw | 3700 | 3650x1800x2500 | |
LGCY-22/8 | 22.0 | 0.8 | 6CTA8.3-C260, 194kw | 4000 | 4250x1950x2500 | |
LGCY-22/13 | 22.0 | 1.3 | YC6M340L-K20, 250kw | 4500 | 4250x1950x2500 | |
LGCY-22/13K | 22.0 | 1.3 | 6LTAA8.9-C325, 239kw | 4500 | 4250x1950x2500 | |
LGCY-22/13S | 22.0 | 1.3 | WD615.46, 266kw | 4500 | 4250x1950x2500 | |
LGCY-21/20 | 21.0 | 2.0 | 6LTAA8.9-C325, 239kw | 4500 | 4450x1950x2650 | |
LGCY-22/20 | 22.0 | 2.0 | YC6M395L-K20, 288kw | 4850 | 4450x1950x2650 | |
LGCY-22/20K | 22.0 | 2.0 | 6LTAA8.9-C360, 265kw | 4500 | 4450x1950x2650 | |
LGCY-22/20 | 22.0 | 2.0 | NTA855-P400, 298kw | 4850 | 4450x1950x2650 | |
LGCY-26/20 | 26.0 | 2.0 | NTA855-P400, 298kw | 4850 | 4450x1950x2650 |
