Screw Air Compressors-Explosive proof air compressor's working conditions:
The air compressor can be in underground near heading face of safe operation, and can move forward with the roadway extension, it can be matched with high pressure, make the pneumatic mechanical efficiency than the ground when gas supply increased by 30% to one time, and power consumption reduction by 30%.
Model NO.: MLGF
Configuration: Explosive and Screw
Power Source: DC Power
Lubrication Style: Oil-free
Motor: >22kw
Capacity: >3.6m3/Min
Max Pressure: 0.7mpa
Voltage: 380/660/1140V
Color: According to Customer
Weight: >1020kg
Brand Name: Zuanshan
Export Markets: Global
Zuanshan Mining Machinery Co., Ltd located in Liaocheng, Shandong Province, we have specilized in research, development and production of this type of screw air compressos for more than 20 years.
| Model | Motor | Capacity | Max pressure | Cool System | Voltage |
| MLGF-3.6/7G-22(KM-30) | 22 | 3.6 | 0.7 | By Wind | 380/660/1140 |
| MLGF-6/7G-37(KM-50) | 37 | 6 | 0.7 | By Wind | 380/660/1140 |
| MLGF-7.6/7G-45(KM-60) | 45 | 7.6 | 0.7 | By Wind | 380/660/1140 |
| MLGF-10/7G-55 (KM-75) | 55 | 10 | 0.7 | By Wind | 380/660/1140 |
| MLGF-16/7G-90 (KM-120) | 90 | 16 | 0.7 | By Wind | 380/660/1140 |
| MLG-21/7G-132 | 132 | 21 | 0.7 | By Wind | 380/660/1140 |
